SECTION 10: PPX NEMA Pump Panels
Table 10-1: NEMA Full-voltage Combination Starters
NEMA size Disconnect Amps Max Total Amps Overload Current Range (Amps) Part Number
208V
1 30
13.5 6.5-13.5 PPX-1A-13-30R
27 13-27 PPX-1A-27-30R
2 60 50 25-50 PPX-2A-50-60R
3 100
70 35-70 PPX-3A-70-100R
100 65-135 PPX-3A-135-100R
4 200 135 65-135 PPX-4A-135-200R
230-240V
1 30
13.5 6.5-13.5 PPX-1B-13-30R
27 13-27 PPX-1B-27-30R
2 60 50 25-50 PPX-2B-50-60R
3 100
70 35-70 PPX-3B-70-100R
100 65-135 PPX-3B-135-100R
460-480V
1 30
13.5 6.5-13.5 PPX-1C-13-30R
27 13-27 PPX-1C-27-30R
2 60 50 25-50 PPX-2C-50-60R
3 100
70 35-70 PPX-3C-70-100R
100 65-135 PPX-3C-135-200R
4 200 135 65-135 PPX-4C-135-200R
5 400 270 130-270 PPX-5C-270-400R
575-600V
1 30 13.5
6.5-13.5 PPX-1D-13-30R
13-27 PPX-1D-27-30R
2 60 50 25-70 PPX-2D-50-60R
3 100
70 35-70 PPX-3D-70-100R
100 65-135 PPX-3D-135-100R
4 200 135 65-135 PPX-4D-135-200R
5 400 270 130-270 PPX-5D-270-400R
Includes complete starter with fusible switch, H-O-A selector switch, START push button, and electronic overload
protection in Type 3R enclosure. Fuses are not included.
