INSTALLING THE BATTERY IN THE BATA BACK
Replace the battery when the data information on
a picture or the LCD panel becomes weak or invis-
ible. The battery will last for approximately 3 years.
The data back uses one 3V lithium battery, type
CR2025.
1. Ensure that a film is not loaded, then open
the back cover.
2. Loosen the battery cover fixing screw
(located near the upper left side of the pres-
sure plate ) with a Phillips head screwdriver,
and then remove the battery chamber cover.
3. Replace the old battery with a new battery
with the + side facing up.
4. Reinstall the battery chamber cover, and
tighten the battery chamber fixing screw.
Note:
If the data indication does not appear on the LCD
panel, it means that the battery has not been
installed properly. After the battery has been
replaced, adjust the data again.
73
ADVANCED OPERATIONS
