peplink 20 User Manual

USER MANUAL
Peplink Balance Series
IPsec VPN Settings
Name
This field is for specifying a local name to represent this connection profile.
Active
When this box is checked, this IPsec VPN connection profile will be enabled. Otherwise, it
will be disabled.
Remote
Gateway IP
Address
Enter the remote peer’s public IP address.For Aggressive Mode, this is optional.
Local Networks
Enter the local LAN subnets here. If you have defined “static routes”, they will be shown
here too.
http://www.peplink.com -82 / 207 - Copyright © 2013 Peplink

peplink 20 Specifications

General

Load Balancing	Yes
VPN Support	Yes
Power over Ethernet (PoE)	No
LAN Ports	4
LAN Interface	4x GE
Wi-Fi Standard	802.11ac
PepVPN/SpeedFusion Throughput (AES 256	200 Mbps
Power Input	12V DC
