Pepperl+Fuchs UC-18GS Series User Manual

UC***-18GS series
Description of Sensor Parameters
2020-11
51
8.3.3 Near Limit
You can use this parameter to adjust the near limit of the analog range in mm, measured from
the ultrasonic transducer surface of the sensor.
8.3.4 Far Limit
You can use this parameter to adjust the far limit of the analog range in mm, measured from the
ultrasonic transducer surface of the sensor.
8.3.5 Lower Output Value
You can use this parameter to set the lower physical output value of the analog output, e.g., 4
mA with a 4..20 mA current output.
Parameter name Access Value range
Analog output – Near limit Read/write <Beginning of adjustment
range> ... <End of adjustment
range< [mm]
(See technical data in the sen-
sor datasheet)
Table 8.12
Note
The DTM also accepts values between <Beginning of sensing range> and <Beginning of
adjustment range> as well as values above <End of adjustment range> up to a certain limit.
Values in these ranges are outside of the adjustment range specified by Pepperl+Fuchs; use
them at your own risk.
Parameter name Access Value range
Analog output – Far limit Read/write <Beginning of adjustment
range> ... <End of adjustment
range< [mm]
(See technical data in the sen-
sor datasheet)
Table 8.13
Note
The DTM also accepts values between <Beginning of sensing range> and <Beginning of
adjustment range> as well as values above <End of adjustment range> up to a certain limit.
Values in these ranges are outside of the adjustment range specified by Pepperl+Fuchs; use
them at your own risk.
Note
The DTM will display just the appropriate lower output value depending on the set output type
for the analog output (current or voltage).
Parameter name Access Value range
Lower output value – Current Read/write 0 ... 20 [mA]
Lower output value – Voltage 0 ... 10 [V]
Table 8.14
