Lambda 25, 35, 45 User’s Guide
102
Changing Fuses
WARNING
Electrical hazard
To prevent potential injury to yourself and damage to the instrument,
switch OFF the instrument and disconnect it from the line power supply
before you change the fuses.
The fuses are located in a fuse holder at the rear of the instrument:
Figure 26 Rear view, fuse holder
1. Switch off the instrument and remove the line power cord from the electrical
supply.
2. Squeeze the two lugs at each side of the fuse holder and gently pull out.
Figure 27 Removing the fuse holder
Fuse Holde
Fuse Holde
