Lambda 25, 35, 45 User’s Guide
92
Replacing a Lamp
Figure 16 Lamp compartment
Figure 17 Inside the Lamp Compartment (Baffle removed)
Lamp compartment
Halogen lamp
assembly
Lamp energy
attenuator
White ceramic
connecto
r
Deuterium lamp
connecto
r
Deuterium lamp
assembly
