Accessories
79
Temperature Sensor
WARNING
Electrical hazard
To prevent potential injury to yourself and damage to the instrument,
switch OFF all instruments in the system and disconnect them from the
line power supply before you alter, or make any new, electrical
connections.
Installation Overview
NOTE: When connecting the temperature sensor, align the red mark on the plug with the red
mark on the socket.
Pull the collar on the plug back to connect/disconnect the plug. Release the collar to
secure the plug (see
Figure 12 page 74).
Connector on Spectrometer:
Temp J10
Installation: See temperature sensor description
Cables: Lead through the tube ports
Sample Compartment Cover: Unchanged
