Explorer Mini Repairs - Base module
Figure 36. Remove the screw from the cover on the
UniTrack® at the front of the base module.
5. Remove the screw from the cover on the UniTrack® at the front of
the base module.
Figure 37. Fold the cover upward.
Figure 38. Remove the cover.
6. Fold the cover upward and remove it.
Figure 39. Remove the cover on the UniTrack® at the
rear of the base module.
7. Remove the screw from the cover on the UniTrack® at the rear of
the base module and remove the cover. If necessary, use a
screwdriver or pliers to loosen the cover from the UniTrack®.
