Pfaff EcoDrive P40 ED User Manual

P40 ED Input
37
▲ = See Chapter 3 Specifi cations of the Instruction Manual for the machine
Group Parameter Description Machine type User level Setting range Set value
5
584 Tack
ON = quadruple,
OFF = double
1, 2, 3, 4, 5 B ON - OFF OFF
585 Speed limitation with tack 1, 2, 3, 4, 5 B 300 - 4800 1000
6
602 Seam end at pedal position
ON = a little in reverse (-1)
OFF = completely in reverse (-2)
1, 2, 3, 4, 5 B ON - OFF OFF
605 Actual speed value in display
ON = on,
OFF = off
1, 2, 3, 4, 5 B ON - OFF OFF
606 Minimum speed 1, 2, 3, 4, 5 B 30 - 650 180
607 Maximum speed 1
2
3
4
5
B
B
B
B
B
300 - 6000
300 - 3200
300 - 5500
300 - 1500
300 - 1200
▲
▲
▲
▲
▲
608 Speed level curve (pedal characteristic)
1 = linear, 2 = non-linear
1, 3, 4, 5
2
B
B
ON - OFF
ON - OFF
ON
OFF
609 Trimming speed 1 1
2, 3
4, 5
B
B
B
60 - 300
60 - 300
60 - 300
210
180
160
615 End recognition with light barrier
ON = from bright to dark,
OFF = from dark to bright
1, 2, 3, 4, 5 B ON - OFF OFF
618 Return after seam end 1, 2, 3, 4, 5 B ON - OFF OFF
623
Switch-on delay for return in [ms]
1, 2, 3, 4, 5 B 0 - 2000 30
631
Angle-controlled switching for thread
tension release
1, 2, 3
4, 5
-
B
-
ON - OFF
-
OFF
636 Thread tension release in conjunction
with presser foot lift
1, 2, 3
4, 5
B
B
ON - OFF
-
OFF
-
