Input P70 ED
50
▲ = See Chapter 3 Specifi cations of the Instruction Manual for the machine
Group
Parameter
Description
Machine type
User level
Setting range
Set value
6
615 End recognition with light barrier
ON = from bright to dark
Off = from dark to bright
1, 2, 3 B ON - OFF OFF
618 Return after seam end 1, 2, 3 B ON - OFF ON
623
Switch-on delay for return in [ms]
1, 2, 3, 4, 5 B 0 - 2550 50
634 Function of switch E 1
ON = Feed adjustment when machine
has stopped and during sewing
OFF = Feed adjustment only during
sewing
1, 2
3
B
-
ON - OFF
-
OFF
-
636 Thread tension release in conjunction
with presser foot lift
1, 2, 3 B ON - OFF OFF
651 Automatic lowering of presser foot
when machine stops
1, 2, 3 B ON - OFF ON
653 Bearing position before sewing 1, 2, 3 B ON - OFF OFF
657 Stitch securing 1, 2, 3 B ON - OFF OFF
660 Bobbin thread monitoring
0 = off,
1 = by sensor
2 = by stitch counting
1, 2, 3 B 0 - 2 0
665 Start inhibitor
ON = when contact closed
OFF = when contact open
1, 2, 3 B ON - OFF OFF
668 Thread wiper 1, 2, 3 B ON - OFF OFF
680 Start inhibitor when drive is running and
machine is tilted back
ON = stop function cycle
OFF = interrupt function cycle
1, 2, 3 B ON - OFF ON
688 Thread tension release in conjunction
with presser foot lift during intermedia-
te stop (parameter 636 = ON)
1, 2, 3 B ON - OFF ON
