P70 ED Input
51
Group
Parameter
Description
Machine type
User level
Setting range
Set value
6
689 Output "wiper" used for
ON = wiper
OFF = thread tension
1, 2, 3 B ON - OFF ON
696 "Needle raised without trimming
switch" function
1 = seam end, after needle raised
without trimming
0 = machine continues sewing
manually
1, 2, 3 B 0 - 1 0
7
700* Needle position 0
Needle reference position
1, 2, 3 B 0 - 255 0
702* 1st needle position (lowered) 1, 2, 3 B 0 - 255 75
703* Thread take-up lever position raised 1, 2
3
B
B
0 - 255
0 - 255
213
225
705* End of cutting signal(magnetic cutting) 1, 2, 3 B 0 - 255 175
706* Start of cutting signal(pneumatic
cutting)
1, 2, 3 B 0 - 255 80
707* Start thread tension release 1, 2
3
B
B
0 - 255
0 - 255
180
185
710* Needle position raised 1, 2, 3 B 0 - 255 200
715 Switch-on time [ms] for thread wiper 1, 2, 3 B 0 - 2550 40
716 Switch-on delay for thread wiper [ms] 1, 2, 3 B 0 - 2550 120
718 Stop brake tacting( 0 = brake off) 1, 2
3
B
B
0 - 40
0 - 40
0
20
721 Tacting output (feed adjustment)
100 = 100 % starting
1, 2, 3 B 10 - 90 40
722 Acceleration ramp for sewing motor
1 = fl at, 50 = steep
1, 2, 3 B 1 - 50 40
723 Brake ramp for sewing motor
1 = fl at, 50 = steep
1, 2, 3 B 6 - 60 45
* = These parameters remain unchanged when the set parameter values are reset,
see Chapter 10.01 Reset / Cold start.
