P70 ED Input
55
Group
Parameter
Description
Machine type
User level
Setting range
Set value
9
939 Hold-back time (premature electrical
switchover) for feed adjustment when
switching on [ms]
1, 2, 3 B 10 - 2000 46
968 Hold-back time (premature electrical
switchover) for feed adjustment when
switching off [ms]
1, 2, 3 B 10 - 200 64
969 Switch off position for presser foot
when thread is clamped at beginning
of seam
1, 2 , 3 B 0 - 255 100
985 Switch on position for thread clamp 1, 2, 3 B 0 - 255 78
986 Switch off position for thread clamp 1, 2, 3 B 0 - 255 213
988 Shortened trim stitch 1, 2, 3 B ON - OFF OFF
989 Thread clamp at beginning of seam
0 = Thread clamp off
1 = Thread clamp without presser
foot lift
2 = Thread clamp with presser foot lift
1, 2, 3 B 0 - 2 0
996 Max. switch on time of electrical
thread clamp after end of seam
1, 2 , 3 B 1 - 600 100
* = These parameters remain unchanged when the set parameter values are reset,
see Chapter 10.01 Reset / Cold start.
