AxN Configurable Motion Control Platform
15
In Storage
As per EN 61800-2，IEC60721-3-1 class 1K3 和 1K4
(2)
Temperature
-25℃ to +85℃
Relative air humidity
5 to 95% without condensation
In Operation
As per EN 61800-2，IEC60721-3-3 class 3K3
(3)
Temperature
0℃ to 40℃，up to 60℃ with power reduction
Relative air humidity
5 to 95% without condensation
(1) The absolute humidity is limited to max. 60 g/m³. This means, at 70 °C for example, that the relative humidity
may only be max. 40 %.
(2) The absolute humidity is limited to max. 29 g/m³. So the maximum values for temperature and relative air
humidity stipulated in the table must not occur simultaneously.
(3) The absolute humidity is limited to max. 25 g/m³. That means that the maximum values for temperature and
relative air humidity stipulated in the table must not occur simultaneously.
Mechanical Conditions
Mechanical Conditions
AxN 09.20.4
Vibration Limit
in Transit
As per EN 61800-2, IEC 60721-3-2 class 2M1
Frequency (𝐇𝐳)
Amplitude (𝐦𝐦)
Acceleration (m/s
2
)
2 ≤ 𝑓 < 9
3.5
Not Applicable
9 ≤ 𝑓 < 200
Not Applicable
10
200 ≤ 𝑓 < 500
Not Applicable
15
Shock Limit in
Transit
As per EN 61800-2, IEC 60721-2-2 class 2M1
Drop height of packed device max. 0.25m
Vibration Limit
of the system
(1)
As per EN 61800-2，IEC 60721-3-3 class 3M1
Frequency (𝐇𝐳)
Amplitude (𝐦𝐦)
Acceleration (m/s
2
)
2 ≤ 𝑓 < 9
0.3
Not Applicable
9 ≤ 𝑓 < 200
Not Applicable
1
(1) NOTE: The devices are only designed for stationary use.
