5.1 Prefabricated Motor Power Output Cable
The Order Code can provide all the necessary specifications about a Prefabricated Motor
Power Output Cable. Choose the specifications and use the corresponding order cable to order.
Order Code
PW
-C
-D16
-5
-GTV
Cable Type
Power Cable
Terminal Type
Motor Side/Drive Side
C = Ring terminal/Cord end terminal
F = Ring terminal/Ring terminal
S = Stripped wires/Cord end terminal
R = Stripped wires/Ring terminal
A = Aviation plug/Cord end terminal
Wire Gauge
(1)
D1.5=4×1.5mm²
B1.5=4×1.5mm²+2×__mm²
D2.5=4×2.5mm²
B2.5=4×2.5mm²+2×__mm²
D04 =4×4mm²
B04 =4×4mm²+2×__mm²
D06 =4×6mm²
B06 =4×6mm²+2×__mm²
D10 =4×10mm²
B10 =4×10mm²+2×__mm²
D16 =4×16mm²
B16 =4×16mm²+2×__mm²
D25 =4×25mm²
B25 =4×25mm²+2×__mm²
Length
3=3m
5=5m
7=7m
X
(2)
=X m
Shield Type
G = General shielded
I = General + Internal shielded
N = No shield
Trace Chain or Not
S = Standard
T = Trace chain
Coat material
V=PVC
U=PUR
(3)
Notes:
1. B in the Wire Gauge means power cable for motor with brake, the gauge of brake wires should
be provided either;
2. Cable Length are not just 3m, 5m and 7m, order whatever cable length you want;
3. Cable Coat made by PUR is oil resistant and wear resistant.
Order Code: PW-C-D16-7-GTV
Power cable; terminal type of motor side is ring terminal, terminal type of drive side is cord end
terminal; wire gauge is 4×16mm²; length is 7m; general shielded; trace chain; insulating layer
material is PVC.
