Phase AxN - Prefabricated Encoder Cable (for Phase Motors)

AxN Configurable Motion Control Platform
58
5.2 Prefabricated Encoder Cable (for Phase Motors)
The Order Code can provide all the necessary specifications about a Prefabricated Encoder
Cable. Choose the specifications and use the corresponding order cable to order.
Order Code
CE
-X
-A28
-5
-ISU
-xx
Cable Type
CN = Endat Encoder
(EQN1325/ECN1313)
CE = Endat Encoder
(ECI1319/EQI1331)
CS = Sincos Encoder
CR = Resolver
CH = Incremental with
Hall sensor
Terminal Type
X=Aviation plug /
DB15(180°outlet)
Y=Aviation
plug/DB15(45°outlet)
Wire Gauge
(1)
A28=AWG28
Length
3=3m
5=5m
7=7m
X
(2)
=X m
Shield Type
G = General shielded
I = General + Internal shielded
N = No shield
Trace Chain or Not
S = Standard
T = Trace chain
Coat material
V=PVC
U=PUR
(3)
Reserve Code
Reserve
Order Code: CE-X-A28-5-ISU
Endat cable(ECI1319/EQI1331); terminal type of motor side is aviation plug, terminal type of drive
side is DB15 connector(180 °outlet); internal diameter is AWG28; length 5m; general and internal
shielded; standard, not trace chain; insulating layer material is PUR.
