PHILIPS 4000 and 3000 05 SERVICE MODE
12/18
Press Espresso Button
Action by user LED INDICATION
Led
NoBeans
Led
NoWater
Led
GenAlarm
Led Dreg
drawer full
Led
Descale
Led
Rinsing
SwitchonRedLedsNoWater&Dregdrawer
full
OFF ON OFF ON OFF OFF
ERROR:LedNoWaterremainsoff,check
theinterfaceboardandatcable(JP21)
OFF ON
ERROR:LedDregdrawerfullremainsoff,
checktheinterfaceboardandatcable
(JP21)
ON OFF
ERROR:LedNoWater&Dregdrawerfull
remainoff,checktheinterfaceboardandat
cable(JP21)
OFF OFF
Press CalcCLean Button
Action by user LED INDICATION
Led
NoBeans
Led
NoWater
Led
GenAlarm
Led Dreg
drawer full
Led
Descale
Led
Rinsing
SwitchonOrangeLedsDescale&Rinsing OFF OFF OFF OFF ON ON
ERROR:LedDescaleremainsoff,checkthe
interfaceboardandatcable(JP21)
OFF ON
ERROR:LedRinsingremainsoff,checkthein-
terfaceboardandatcable(JP21)
ON OFF
ERROR:LedDescale&Rinsingremainoff,
checktheinterfaceboardandatcable
(JP21)
OFF OFF
Press Coffee Button
Action by user LED INDICATION
Led
NoBeans
Led
NoWater
Led
GenAlarm
Led Dreg
drawer full
Led
Descale
Led
Rinsing
SwitchonRedLedsGenAlarm&NoBeans ON OFF ON OFF OFF OFF
ERROR:LedNoBeansremainsoff,check
theinterfaceboardandatcable(JP21)
OFF ON
ERROR:LedGenAlarmremainsoff,check
theinterfaceboardandatcable(JP21)
ON OFF
ERROR:LedNoBeans&GenAlarmremain
off,checktheinterfaceboardandatcable
(JP21)
OFF OFF
Press Steam Button
Action by user LED INDICATION
Led Steam Button Led Hot-Water Button
Switch on green Led under the Steam
Button
ON OFF
ERROR:LedSteamremainsoff,checkthe
interfaceboardandatcable(JP21)
OFF OFF
