Philips Q552.2E - 11 Styling Sheets

Styling Sheets
EN 199Q552.2E LA 11.
2011-Jun-01
back to
div. table
11. Styling Sheets
11-1 Blockbuster 32"
19100_806_110210.eps
110214
BLOCKBUSTER 32"
Pos No. Description Remarks
0004 Front Cabinet
0011 Back Cover
0029 Hard Switch bracket
0260 Stand
1004 Display panel
1005 Power Supply Unit
1085 Remote Control Not displayed
1108 Keyboard + IR assy
1150 Board SSB
5213 Loudspeaker box
5216 Tweeter
8191 Mainscord 1.8m Not displayed
8308 Main (power) switch
8G50 Cable LVDS FFC Not displayed
8G51 Cable LVDS FFC Not di
splayed
0260
1005
5213
0011
5216
0029
1150
5216
8308
1004
0004
1108
