Philips Q552.2E - Blockbuster 37

EN 200Q552.2E LA 11.
Styling Sheets
2011-Jun-01
back to
div. table
11-2 Blockbuster 37"
19100_810_110214.eps
110217
BLOCKBUSTER 37"
Pos No. Description Remarks
0004 Front Cabinet
0011 Back Cover
0029 Hard Switch bracket
0260 Stand
1004 Display panel
1005 Power Supply Unit
1085 Remote Control Not displayed
1108 Keyboard + IR assy
1150 Board SSB
5213 Loudspeaker box
5216 Tweeter
8191 Mainscord 1.8m Not displayed
8308 Main (power) switch
8G50 Cable LVDS FFC Not displayed
8G51 Cable LVDS FFC Not di
splayed
0029
0011
0260
1005
1004
8308
1150
0004
1108
5216
5216
5213
