Philips Q552.2E - Sundance 32

Styling Sheets
EN 203Q552.2E LA 11.
2011-Jun-01
back to
div. table
11-5 Sundance 32"
19100_820_110505.eps
110505
SUNDANCE 32"
Pos No. Description Remarks
0062 Main switch + bracket with cable
0004 Front Cabinet
1004 Display panel
1163 Ambilight module
1108 Keyboard touch control assy
1005 Power Supply Unit
0260 Stand assy
5216 Tweeter
0011 Back Cover
5213 Loudspeaker box
0035 Swivel Bracket
1027 Temperature Sensor Not Displayed
1150 Board SSB
8191 Mainscord 1.8m Not Di
splayed
8G50 Cable LVDS FFC Not Displayed
8G51 Cable LVDS FFC Not Displayed
1085 Remote Control Not Displayed
1108
0004
1004
0062
1163
0260
1005
0011
5213
5216
1150
0035
1163
5216
