Philips Q552.2E - Blockbuster 40& 46

Styling Sheets
EN 201Q552.2E LA 11.
2011-Jun-01
back to
div. table
11-3 Blockbuster 40"& 46"
19100_802_110202.eps
110307
BLOCKBUSTER 40"- 46"
0004 Front Cabinet
0011 Back Cover
0040 Hard Switch bracket
0260 Stand
1004 Display panel
1005 Power Supply Unit
1085 Remote Control Not Displayed
1108 Keyboard + IR assy
1150 Board SSB
5213 Loudspeaker box
5216 Tweeter
8191 Mainscord 1.8m Not Displayed
8308 Main (power) switch with cable
8G50 Cable LVDS FFC Not Displayed
8G51 Cable LVDS FFC Not Displayed
POS. NO. DESCRIPTION. REMARKS
5213
0011
0260
0040
0004
1004
1108
5216
8308
1150
1005
5216
