Alignments
EN 44 Q552.2E LA6.
2011-Jun-01
back to
div. table
If you do not have a colour analyser, you can use the default
values. This is the next best solution. The default values are
average values coming from production.
• Select a COLOUR TEMPERATURE (e.g. COOL,
NORMAL, or WARM).
• Set the RED, GREEN and BLUE default values according
to the values in Table 6-3
to Table 6-15.
• When finished press OK on the RC, then press STORE (in
the SAM root menu) to store the aligned values to the NVM.
• Restore the initial picture settings after the alignments.
Table 6-3 White tone default setting 32" (Blockbuster)
Table 6-4 White tone default setting 37" (Blockbuster)
Table 6-5 White tone default setting 40" (Blockbuster)
Table 6-6 White tone default setting 46" (Blockbuster)
Table 6-7 White tone default setting 55" (Blockbuster)
Table 6-8 White tone default setting 32" (Sundance)
Table 6-9 White tone default setting 42" (Sundance)
Table 6-10 White tone default setting 47" (Sundance)
Table 6-11 White tone default setting 32" (Sundance 3D)
Table 6-12 White tone default setting 37" (Sundance 3D)
Table 6-13 White tone default setting 42" (Sundance 3D)
Table 6-14 White tone default setting 47" (Sundance 3D)
Table 6-15 White tone default setting 55" (Sundance 3D)
6.4 Option Settings
6.4.1 Introduction
The microprocessor communicates with a large number of I
2
C
ICs in the set. To ensure good communication and to make
digital diagnosis possible, the microprocessor has to know
which ICs to address. The presence / absence of these
PNX51XX ICs (back-end advanced video picture improvement
IC which offers motion estimation and compensation features
(commercially called HDNM) plus integrated Ambilight control)
is made known by the option codes.
Notes:
• After changing the option(s), save them by pressing the OK
button on the RC before the cursor is moved to the left,
select STORE in the SAM root menu and press OK on the
RC.
• The new option setting is only active after the TV is
switched “off” / “stand-by” and “on” again with the mains
switch (the NVM is then read again).
White Tone e.g. 32PFL66x6x
Colour Temp R G B
Normal 127 125 104
Cool 123 127 119
Warm 127 116 62
White Tone e.g. 37PFL66x6x
Colour Temp R G B
Normal 122 104 127
Cool 103 91 127
Warm 127 98 84
White Tone e.g. 40PFL66x6x
Colour Temp R G B
Normal 124 126 109
Cool 118 126 123
Warm 127 120 69
White Tone e.g. 46PFL66x6x
Colour Temp R G B
Normal 127 123 96
Cool 126 126 113
Warm 127 120 54
White Tone e.g. 55PFL66x6x
Colour Temp R G B
Normal t.b.d. t.b.d. t.b.d.
Cool t.b.d. t.b.d. t.b.d.
Warm t.b.d. t.b.d. t.b.d.
White Tone e.g. 32PFL74x6x
Colour Temp R G B
Normal 112 110 127
Cool 74 98 127
Warm 127 111 95
White Tone e.g. 42PFL74x6x
Colour Temp R G B
Normal 111 115 127
Cool 94 104 127
Warm 127 118 96
White Tone e.g. 47PFL74x6x
Colour Temp R G B
Normal t.b.d. t.b.d. t.b.d.
Cool t.b.d. t.b.d. t.b.d.
Warm t.b.d. t.b.d. t.b.d.
White Tone e.g. 32PFL76x6x
Colour Temp R G B
Normal 108 114 127
Cool 90 103 127
Warm 127 121 103
White Tone e.g. 37PFL76x6x
Colour Temp R G B
Normal 126 125 127
Cool 112 112 127
Warm 127 113 86
White Tone e.g. 42PFL76x6x
Colour Temp R G B
Normal 122 125 126
Cool 111 113 127
Warm 127 117 84
White Tone e.g. 47PFL76x6x
Colour Temp R G B
Normal t.b.d. t.b.d. t.b.d.
Cool t.b.d. t.b.d. t.b.d.
Warm t.b.d. t.b.d. t.b.d.
White Tone e.g. 55PFL76x6x
Colour Temp R G B
Normal t.b.d. t.b.d. t.b.d.
Cool t.b.d. t.b.d. t.b.d.
Warm t.b.d. t.b.d. t.b.d.
