Philips Q552.2E - Sundance 42 & 47

EN 204Q552.2E LA 11.
Styling Sheets
2011-Jun-01
back to
div. table
11-6 Sundance 42" & 47"
19100_821_110505.eps
110505
SUNDANCE 42" - 47"
Pos No. Description Remarks
0062 Main switch + bracket with cable
0004 Front Cabinet
1004 Display panel
1163 Ambilight module
1108 Keyboard touch control assy
1005 Power Supply Unit
0257 Stand neck
0258 Stand base
5216 Tweeter
0011 Back Cover
5213 Loudspeaker box
0035 Swivel Bracket
0026 Wifi Bracket Not Displayed
1115 Wifi module Not Displayed
1027 Temperature Sensor Not Di
splayed
1150 Board SSB
0270/0269 3D Glasses Not Displayed
8191 Mainscord 1.8m Not Displayed
8G50 Cable LVDS FFC Not Displayed
8G51 Cable LVDS FFC Not Displayed
1085/1185 Remote Control Not Displayed
1108
0004
1004
5216
1163
0258
0257
0011
5213
0035
0062
1150
1005
0024
0026
0021
5216
1163
1151
