62 EN EN 63
• One-Key Recording is not supported during start or
shutdown. Only after device is turned on can One-Key
Recording be started.
• When power is less than 5%, the recorded audios will be
stored and recording will be stopped.
5.2 Use an External Microphone to Record
When using an external microphone to record, please first
plug it into the Line in socket, and then record according to
the procedures of built-in microphone. After you connect
the external microphone, the built-in microphone is disabled
automatically. Please Reminder that the plug of the external
microphone must be stereo plug, and recording directly from
speaker is not supported.
Introduction on the Use of External Microphone Recording
Function:
1.When using an external microphone for recording,
place such device into the Line In socket and then follow
the instructions on recording as the built-in microphone
recording mode.
2.When using external microphone for recording, please
use the Line-in line.One end of the Line-in line is connected
with the external microphone and the other end is inserted
into the Line-in socket, and then follow the instructions on
recording as the built-in microphone recording mode.
Reminder
• When using an external microphone for recording, the
microphone should be placed near the sound source and
the volume can be adjusted via Gain Setting. Please refer
to Section 5.1 for details on the Gain Setting.
• When using an external microphone for recording, please
adjust the external sound to appropriate levels and then
start recording.
5.3 Use a Telephone to Record
he steps for recording phone conversations are as follows:
Connect the external telephone cable and accessory
connection line with the telephone recording adapter as
shown below. After connection, click the recording icon on
the Main Menu and select Tel Recording as the mode. Then
record as the built-in microphone recording mode.
Reminder
• Gain Setting can not be set during Telephone Recording
mode.
To Next Page
