Technical data and ordering data
7805_en_02 PHOENIX CONTACT 5-5
Digital inputs
Number 8
Input design According to EN 61131-2 Type 1
Definition of switching thresholds
Maximum low-level voltage 5 V DC
Minimum high-level voltage 15 V DC
Nominal input voltage 24 V DC
Permissible range -0.5 V < U
IN
< +30 V DC
Nominal input current at 24 V 7 mA, typical; 15 mA, maximum
Hardware filter times (typical)
Inputs I1 to I8
Signal change 0 -> 1
Signal change 1 -> 0
5 ms
5 ms
Permissible cable length to the sensor 30 m (to ensure conformance with EMC directive 89/336/EEC)
Use of AC sensors AC sensors in the voltage range < U
IN
are limited in application (according to
the input design)
Digital outputs
Number 4
Output design Protected outputs according to EN 61131-2
Nominal output voltage 24 V DC
Nominal output current 500 mA
Diagnostic and status indicators
IEC 61131 runtime system (PLC) FR, FF
Ethernet (ETH) LINK, ACT
INTERBUS diagnostics (IL) RDY, BSA, FAIL, PF
Digital inputs and outputs I1 to I8, E, Q1 to Q4
Supply voltages US, UM, UL
