Number of devices in the INTERBUS system
Total number of bus devices 128, maximum
Number of remote bus devices
ILC 130 ETH
ILC 150 ETH, ILC 155 ETH, ILC 170 ETH 2TX
–
32, maximum
Number of PCP devices
ILC 130 ETH, ILC 150 ETH, ILC 155 ETH
ILC 170 ETH 2TX
8
16
Number of remote bus levels
ILC 130 ETH
ILC 150 ETH, ILC 155 ETH, ILC 170 ETH 2TX
see Section 2.2 on page 2-2
–
4, maximum
Please note that the ILC 130 ETH does not support connection of the INTERBUS remote bus.
Network interface
Type
ILC 130 ETH, ILC 150 ETH, ILC 155 ETH
ILC 170 ETH 2TX
1 x Ethernet; 10Base-T and 100Base-TX
2 x Ethernet; 10Base-T and 100Base-TX
Speed 10 Mbits (10Base-T), 100 Mbits (100Base-TX)
half duplex, full duplex, auto negotiation
Connection method Cat. 5 twisted pair cable
RJ45 female connector
This speed cannot be set manually. It is set automatically by means of auto negotiation.
Inline local bus
Interface Inline local bus
Electrical isolation No
Number of devices 128, maximum
Diagnostic interface
Connection method 6-pos. Mini-DIN female connector (PS/2)
Interface type V.24 (RS-232)
Transmission speed 9600 baud
Electrical isolation No
