Optical Fiber Connector for Polymer Fibers
Designation: OPTOSUB-MA/M/R-LK
Figure 46 IBS OPTOSUB cabling
Refer to the package slips of the following items when
assembling your own optical fiber cables, or order
pre-assembled cables from Phoenix Contact.
Ordering data:
IBS OPTOSUB-MA/M/R-LK Order No. 27 50 12 5
F-SMA/4 connector set with bending protection
(4 connectors)
PSM-SET-FSMA/4 Order No. 27 99 72 0
Polishing set
PSM-SET-FSMA-POLISH Order No. 27 99 34 8
Optical Fiber Installation Guidelines
IBS SYS FOC ASSEMBLY Part No. 94 23 43 9
Make sure that the power supply of the PLC is
switched off when plugging the OPTOSUB connector
in the controller board.
5756A040
