Description
Introduction This section describes the features, specifications, and circuitry for the
accessory LIFEPAK 9 shock advisory adapter. This section is divided
into three parts:
e © Physical Description describes general features and lists
specifications
e Functional Description briefly describes the function of the major
assemblies
e © Theory of Operation provides circuit descriptions to the major
component level.
Physical The LIFEPAK 9 functions as an automatic advisory defibrillator when
Description
the adapter is used. The adapter fits into the paddle wells on the front on
the LIFEPAK 9 defibrillator/monitor when the standards paddles are
removed (see Figure 1-1). The adapter can be used with any of the
LIFEPAK 9 family of defibrillator/monitor/pacemakers. These are:
© November 1994 Physio-Control Corporation
LIFEPAK 9 defibrillator/monitor
LIFEPAK 9A defibrillator/monitor
LIFEPAK 9B defibrillator/monitor
LIFEPAK 9P defibrillator/monitor/pacemaker
