LIFEPAK
9
defibrillator/monitor
when
they
are
required
for
a
particular
function.
This
data
is
transmitted
in
packets
containing
a
header
byte,
two
ECG
sample
bytes,
and,
if
required,
a
data/command
byte.
The
first
four
VO
lines
listed
in
Table
1-4
communicate
with
the
Display
Gate
Array,
U29,
driving
the
input
for
the
Display
PCB.
The
other
five
YO
lines
control
the
operation
of
the
recorder.
Table
1-4
Display/Recorder
Microprocessor
VO
Lines
VO
Line
Signal
Direction
P(50)
H.RETR
In
P(52)
GO
Out
P(53)
|INCMEM
Out
P(54)
|TR/CHAR
Out
P(21)
STROBE
Out
P(60)
RECORDER
POWER
Out
P(61)
PRINTHEAD
CURRENT
SENSE
In
P(66)
PRINTHEAD
TYPE
In
P(67)
PRINTHEAD
LOAD
Out
System
Clock.
Crystal-controlled
multiple-output
oscillator
U10
provides
a
>
16MHz
square
wave
to
the
Display
Gate
Array.
It
also
supplies
8MHz
to
both
the
System
and
Display/Recorder
microprocessors
(U30
and
U1),
and
2MHz
to
A/D
converter
U9
on
the
Power
Conversion
PCB.
Address
Decode.
Programmable
logic
array
U9
controls
the
reading
from
and
the
writing
to
all
external
memory
and
the
Recorder
Gate
Array,
U3.
U9
functions
as
an
address
decoder
and
is
programmed
to
enable
the
appropriate
devices
when
the
Display/Recorder
microprocessor
addresses
different
areas
in
memory.
Buffers
U11,
U12,
and
U1S5
isolate
the
appropriate
RAM/ROM
memory
devices
from
interaction
with
the
Display/Recorder
microprocessor.
U11
buffers
the
data
bus.
Buffers
U12
and
U15
control
interaction
on
the
address
bus
between
the
Display/Recorder
microprocessor,
the
Display
Gate
Array,
and
the
RAM/ROM
memory
devices.
Display
Gate
Array.
Display
Gate
Array
U29
is a
custom
IC
containing
many
blocks
of
standard
OR
and
AND
gate
circuits
(counters,
multivibrators,
flip-flops,
etc.).
A
metalized
layer
added
on
top
of
the
gate
circuits
connects
only
those
circuits
needed
for
a
specific
function:
Monitor
PCB
sync
timing,
ECG
memory
addressing,
ECG
display
trace
generation,
video
intensity,
and
additional
timing
signal
generation.
Two
different
internal
counters
control
1-26
All
Rights
Reserved
O
August
1993
Physio-Control
