8 GCS Commands
C-863.12 Mercury Controller MS249E Version: 1.2.1 161
{<PamID> <ItemID> “=” <ListType>
[ {TAB <PossibleValue> “=” <ValueDescription>} ] }
#CCL levels are:
{<PamID> <ItemID> “=”<CmdLevel> }
#HPA_Category enabled
end of help”
where
<PamID> is the ID of one parameter, hexadecimal format
<ItemID> is one item (axis, channel, whole system) of the
controller, if item=0 the description applies to all items
<ListType> determines how the possible parameter values
listed in the string have to be interpreted:
0 = parameter not applicable for this item
1 = enumeration
2 = min/max
<PossibleValue> is a value from the permissible data range
<ValueDescription> is the meaning of the corresponding
value
Some parameters are write protected (by a command level
> 1) for certain items. These parameters are listed below
the “#CCL levels are” line.
<CmdLevel> is the command level that allows write access
to the parameter value.
The "#HPA_Category enabled" line is evaluated by the PC
software for display purposes.
Notes:
For C-863.12, the specifications
#Possible parameter values are:
and
#CCL levels are:
are left out of the response to HPV?, because all required
information is already in the response to HPA?
