6 Startup
52 Version: 1.2.1 MS249E C-863.12 Mercury Controller
Switch
Function
1 to 4
Controller address (p. 52)
5 and 6
Baud rate (p. 53)
7 and 8
Without function
Requirements
✓ The C-863.12 is switched off, i.e., the power supply is not connected to the power
socket with the power cord.
Adapting the DIP switch settings
➢ Put the individual DIP switches in the correct position for your application. Details are
specified in the following tables.
6.2.2 Controller Address
Address*
S1
S2
S3
S4
1
ON
ON
ON
ON
2
ON
ON
ON
OFF
3
ON
ON
OFF
ON
4
ON
ON
OFF
OFF
5
ON
OFF
ON
ON
6
ON
OFF
ON
OFF
7
ON
OFF
OFF
ON
8
ON
OFF
OFF
OFF
9
OFF
ON
ON
ON
10
OFF
ON
ON
OFF
11
OFF
ON
OFF
ON
12
OFF
ON
OFF
OFF
13
OFF
OFF
ON
ON
14
OFF
OFF
ON
OFF
15
OFF
OFF
OFF
ON
16
OFF
OFF
OFF
OFF
*Factory default settings are shown in bold.
