13 Technical Data
262 Version: 1.2.1 MS249E C-863.12 Mercury Controller
Electrical properties
C-863.12
Power consumption, full load
48 W
Power consumption without load
3 W
Current limitation
2.5 A
Interfaces and operation
C-863.12
Communication interfaces
USB; RS-232, D-sub 9 (m)
Motor connector
HD D-sub 26 (f)
Controller network
Up to 16 units** on a single interface
I/O lines
4 analog / digital inputs (0 to 5 V / TTL), 4 digital outputs (TTL)
Command set
PI General Command Set (GCS)
User software
PIMikroMove
Application programming interfaces
API for C / C++ / C# / VB.NET / MATLAB / Python, drivers for NI
LabVIEW
Manual control
Joystick, Y cable for 2-D motion, pushbutton box
Miscellaneous
C-863.12
Operating voltage
12 to 48 V DC *** from external power adapter (24 V DC power
adapter included in the scope of delivery)
Max. current consumption
40 mA without load (when supplied with 48 V)
80 mA without load (when supplied with 24 V)
Operating temperature range
5 to 50 °C (temperature protection switches off at excessively high
temperatures)
Mass
0.48 kg
Dimensions
130 mm × 76 mm × 40 mm (incl. mounting rails)
* The output voltage depends on the power adapter connected.
** 16 units with USB; 6 units with RS-232.
*** Recommended operating voltage: 24 to 48 V DC
