PIAGGIO Beverly 400 E5 - Page 130

- Remove the retainer rings and remove the piston.
N.B.
BE CAREFUL NOT TO DAMAGE THE SEALING RINGS
DURING REMOVAL.
Inspecting the small end
N.B.
TO MEASURE WEAR LIMITS AND COUPLING CLEARANCES, SEE THE SPECIFICATIONS CHAP-
TER.
Inspecting the piston
N.B.
TO MEASURE WEAR LIMITS AND COUPLING CLEARANCES, SEE THE SPECIFICATIONS CHAP-
TER.
Inspecting the piston rings
N.B.
TO MEASURE WEAR LIMITS AND COUPLING CLEARANCES, SEE THE SPECIFICATIONS CHAP-
TER.
Removing the piston
- Insert the pin.
- Insert the retainer rings.
CAUTION
POSITION THE ARROW PRINTED ON THE PISTON
CROWN TOWARDS THE EXHAUST OPENING.
CAUTION
AT EVERY NEW MOUNTING USE RETAINER RING PINS.
Engine Beverly 400 E5
ENG - 130
