PIAGGIO Runner 125 - Exhaust assy. Removal; Removal of the engine from the vehicle

Questa sezione descrive le operazioni da effettuare per lo smontaggio del motore dal veicolo.
Exhaust assy. Removal
•
Unscrew the 3 screws fixing the muffler
to the engine crankcase and the sup-
porting arm;
•
Loosen the bolt holding the muffler to
the exhaust manifold; after that, re-
move the muffler backwards.
•
Unscrew the 2 nuts that fix the exhaust
manifold to the head and remove it.
Removal of the engine from the vehicle
- Remove the rear mudguard supporting bracket
undoing the 3 screws.
- Remove the whole muffler, the shock absorber/
wheel supporting bracket and the rear wheel.
Engine from vehicle Runner 125 - 200
ENG VE - 118
