Oversizes
ENGINE 125 OVERSIZE
Name
Description Dimensions Initials Quantity
Compression ring 57 x 1 A 0.15 ÷ 0.30
Oil scraper ring 57 x 1 A 0.10 ÷ 0.30
Oil scraper ring 57 x 2.5 A 0.15 ÷ 0.35
Compression ring 1st
oversize
57.2 x 1 A 0.15 ÷ 0.30
Oil scraper ring 1st
Oversize
57.2 x 1 A 0.10 ÷ 0.30
Oil scraper ring 1st
Oversize
57.2 x 2.5 A 0.15 ÷ 0.35
Compression ring 2nd
Oversize
57.4 x 1 A 0.15 ÷ 0.30
Oil scraper ring 2nd
Oversize
57.4 x 1 A 0.10 ÷ 0.30
Oil scraper ring 2nd
Oversize
57.4 x 2.5 A 0.15 ÷ 0.35
Compression ring 3rd
Oversize
57.6 x 1 A 0.15 ÷ 0.30
Oil scraper ring 3rd
Oversize
57.6 x 1 A
Oil scraper ring 3rd
Oversize
57.6 x 2.5 A 0.15 ÷ 0.35
ENGINE 200 OVERSIZE
Name
Description Dimensions Initials Quantity
Oil scraper ring 72 x 2.5 A 0.20 ÷ 0.40
Oil scraper ring 72 x 1 A 0.20 ÷ 0.40
Compression ring 72 x 1.5 A 0.15 ÷ 0.30
Characteristics Runner 125 - 200
CHAR - 22
