Front handlebar cover
-Remove the rear-view mirrors.
-Remove the two screws shown in the figure, and
at the same time disconnect the fitting in the upper
part of the handlebar cover. Pull the front part up-
wards so as not to damage the fittings made of
plastic.
Headlight assy.
- Remove the front shield
- Remove the 2 screws indicated in the photograph
at the back of the shield, then disconnect the wiring
and remove the headlight assembly.
See also
Legshield
Frame central cover
Remove the saddle and the two screws indicated
in the photograph.
- Remove the air ducts, then operate the screw in-
dicated in photograph.
Chassis Runner 125 - 200
CHAS - 270
