PIAGGIO Runner 125 - Hub oil

THE SPARK PLUG MUST BE REMOVED WHEN THE MO-
TOR IS COLD. THE SPARK PLUG MUST BE REPLACED
EVERY 12,000 KM. THE USE OF NON CONFORMING IGNI-
TION CONTROL UNITS OR SPARK PLUGS OTHER THAN
THOSE PRESCRIBED CAN SERIOUSLY DAMAGE THE EN-
GINE.
Characteristic
Electrode gap
0.7-0.8 mm
Electric characteristic
Recommended spark plug (125)
CHAMPION RG4HC - NGK CR8EB
Recommended spark plug (200)
CHAMPION RG6YC - NGK CR8EB
Locking torques (N*m)
Spark plug 12 ÷ 14
Hub oil
Check
-Stand the vehicle on its centre stand on flat
ground;
-Remove the oil dipstick "A", dry it with a clean
cloth and put it back into its hole tightening it
completely;
-Take out the dipstick checking that the oil level
reaches the dipstick lower notch; if the level is un-
der the MAX. mark, it needs to be filled with the
right amount of hub oil.
-Screw up the oil dipstick again and make sure it
is locked properly into place.
Maintenance Runner 125 - 200
MAIN - 42
