SERIES FE
EN
LOW-PRESSURE GAS REGULATOR | FUNCTIONAL CHECKS | REV. 00
Use, maintenance and warning manual
8.2 - PERIODICALLY CHECKING AND INSPECTING THE EQUIPMENT FOR PROPER
OPERATION
HAZARD!
Checks and inspections must be carried out only by qualied technicians.
Periodic checks and inspections
Operator qualication • Commissioning technician.
PPE required
WARNING!
The PPE listed in this table is related to the risk associated with the equipment.
For the PPE required to protect against risks associated with the workplace,
installation or operating conditions, please refer to:
• the regulations in force in the country of installation;
• any information provided by the Safety Manager at the installation facility.
Tab. 8.43.
8.2.1 - FUNCTIONAL CHECKS OF SAFETY DEVICES
To check the safety devices for proper operation, it is necessary:
• that the system has a shut-off valve downstream of the regulator;
• that the system is set up with a pressure outlet downstream of the regulator or that the regulator is equipped with a
built-in pressure outlet (see paragraph 4.6.4);
• that an external pressure source with pressure control is available;
• that the external pressure source is connected to a pressure gauge and to a tap with a 4 mm maximum ow section.
NOTE!
Gas dispersions in the environment must be reduced to the bare minimum.
To check the safety devices, proceed as described in Tab. 8.44.:
Step Action
1 Close the valve downstream of the regulator.
2
Prepare the external pressure source with a pressure gauge to monitor the pressure.
NOTE!
The maximum pressure introduced downstream of the regulator must not exceed:
• 300 mbar for the BP version;
• 1 bar for the TR version.
3
Connect the external pressure source to the pressure outlet downstream of the system or, if any, to the pres-
sure outlet on the regulator.
NOTE!
To use the pressure outlet on the regulator, see paragraph 4.6.4.
4a
Pds (adjusted pressure) check:
1. open the tap of the external pressure source;
2. check that the pds value is ± 10% with respect to the value indicated on the nameplate applied.
4b
Internal sealing check:
1. close the tap of the external pressure source;
2. check that the downstream pressure value is stable over time (wait for about 2 minutes).
