Installation
Operating Manual PNOZ m C0
1006013-EN-02
| 20
6.1.1 Mounting distances
With control cabinet installation it is essential to maintain a certain distance from the top
and bottom, as well as to other heat-producing devices (see diagram). The values stated
for the mounting distances are minimum specifications.
The ambient temperature of the product in the control cabinet must not exceed the figure
stated in the technical details, otherwise air conditioning may be required.
Mounting distances:
Heat-generating device
Heat-generating device
INFORMATION
Please note that at the stated minimum distance, it will be difficult to swap
the chip card from above. If you cannot leave a greater distance, remove
the unit from the mounting rail to swap the chip card.
