Pilz PNOZ m C0 User Manual

Technical details
Operating Manual PNOZ m C0
1006013-EN-02
| 33
Mechanical data
Weight 105 g
Where standards are undated, the 2022-02 latest editions shall apply.
11.1 Safety characteristic data
NOTICE
You must comply with the safety characteristic data in order to achieve the
required safety level for your plant/machine.
Unit Operating
mode
EN ISO
13849-1:
2015
PL
EN ISO
13849-1:
2015
Category
EN IEC
62061
SIL CL/
maximum
SIL
EN IEC
62061
PFH
D
[1/h]
EN/IEC
61511
SIL
EN/IEC
61511
PFD
EN ISO
13849-1:
2015
T
M
[year]
Input
Inputs 1-channel PL d Cat. 2 SIL 2 7,75E-09 SIL 2 6,80E-04 20
Inputs 2-channel PL e Cat. 4 SIL 3 1,65E-10 SIL 3 1,42E-05 20
Inputs 1-ch.,
pulsed
light bar-
rier PL e Cat. 4 SIL 3 7,75E-10 SIL 3 6,85E-05 20
Output
SC outputs 1-channel
with ad-
vanced
fault de-
tection PL e Cat. 4 SIL 3 4,49E-10 SIL 3 3,84E-05 20
SC outputs 1-channel PL d Cat. 2 SIL 2 7,08E-10 SIL 2 6,03E-05 20
SC outputs 2-channel PL e Cat. 4 SIL 3 4,66E-10 SIL 3 4,00E-05 20
Explanatory notes for the safety-related characteristic data:
} Safety characteristic data in accordance with EN IEC 62061 and EN/IEC 61511 was cal-
culated based on EN/IEC 61508.
} T
M
is the maximum mission time in accordance with EN ISO 13849-1. The value also ap-
plies as the retest interval in accordance with EN/IEC 61508-6 and EN/IEC 61511 and as
the proof test interval and mission time in accordance with EN IEC 62061.
All the units used within a safety function must be considered when calculating the safety
characteristic data.
