Overview
Operating Manual PNOZ m C0
1006013-EN-02
| 7
2 Overview
2.1 Range
} Base unit PNOZ m C0
2.2 Unit features
Application of the product PNOZ m C0:
Standalone base unit of the configurable control system PNOZmulti 2
The product has the following features:
} Can be configured in the PNOZmulti Configurator
} Semiconductor outputs:
4 safety outputs
depending on the application, up to PL e of EN ISO 13849-1 and up to SIL 3 of EN IEC
62061
} 8 safe inputs for connecting, for example:
– Emergency stop pushbuttons
– Two-hand pushbuttons
– Safety gate limit switches
– Start buttons
– Light barriers
– Scanner
– Enabling switches
– PSEN
– Operating mode selector switches
Alternatively, inputs IM0 and IM1 can be configured as signal outputs.
The pulse suppression time for the inputs can be changed in the PNOZmulti Configurator.
A change of the preset pulse suppression time (see Technical details [ 30]) can be
used to suppress the self-monitored outputs and for interference suppression.
} 2 configurable outputs
Can be configured as:
– Test pulse outputs
or
– Signal outputs
} LED display for:
– Supply voltage
– Run operating state
– Diagnostics
– Internal and external fault
– Fault at the outputs
