Pilz PNOZ m0p

6.2 Ethernet interfaces (only PNOZ m0p ETH)
6 Commissioning
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de
6-4
Fig. 6-1: PNOZmulti as Ethernet subscriber - possible topologies
Ethernet
Hub/Switch Hub/Switch
Ethernet subscriber
Ethernet subscriber
PNOZmulti base unit
with Ethernet interface
PNOZmulti base unit
with Ethernet interface
PC with PNOZmulti
Configurator
