8.1 Technical details
8 Technical details
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de
8-2
Utilisation category in accordance with EN 60947-4-1
Safety contacts: AC1 at 240 V 6.0 A, 1440 VA
Safety contacts: DC1 at 24 V 6.0 A, 144 W
Utilisation category in accordance with EN 60947-5-1
Safety contacts: AC15 at 230 V 3.0 A, 690 W
Safety contacts: DC13 at 24 V (6 cycles/min) 3.0 A, 72 W
Airgap creepage between
relay contacts 3 mm
relay contacts and other safe circuits 5.5 mm
External contact fuse protection (I
K
= 1 kA) to
EN 60947-5-1
Blow-out fuse, quick 6 A
Blow-out fuse, slow 6 A
Circuit breaker 24 VAC/DC, characteristic B/C 6 A
Switch-off delay 50 ms
Auxiliary outputs
Number 1
Switching capability
voltage 24 V
current 0.5 A
power 12.0 W
Galvanic isolation yes
Short circuit-proof yes
Residual current at "0" 0.5 mA
Signal level at "1" UB - 0.5 V DC bei 0.5 A
Cascading output as auxiliary output
Number 1
Switching capability
voltage 24 V
current 0.2 A
power 4.8 W
Galvanic isolation no
Short circuit-proof yes
Residual current at "0" 0.5 mA
Environmental data
EMC EN 60947-5-1
Vibration to EN 60068-2-6
Frequency 10 - 55 Hz
Amplitude 0.35 mm
Climatic suitability EN 60068-2-78
Airgap creepage in accordance with EN 60664-1
Ambient temperature 0 - 60 °C
Storage temperature -25 - 70 °C
Mechanical data
Protection type
Mounting (e.g. cabinet) IP54
Housing IP20
Terminals IP20
DIN rail
Top hat rail 35 x 7.5 EN 50022
Recess width 27 mm
