Pioneer PDP-507XD Service Manual

PDP-507XD
107
5678
56
7
8
C
D
F
A
B
E
6. DISASSEMBLY
6.1 PCB LOCATION
SIDE KEY Assy SIDE Assy
50 Y SUB DRIVE
Assy
50 X SUB DRIVE
Assy
SENSOR Assy
PC Assy
TANSHI
Assy
SP TERMINAL
Assy
50 Y MAIN DRIVE
Assy
50 X MAIN DRIVE
Assy
50 SCAN B Assy50 SCAN A Assy
AUDIO
Assy
50 DIGITAL
Assy
MAIN Assy
R07 DT Assy
PDP-507XD only
POWER SUPPLY
Unit
LED IR Assy
Rear view
50 LED Assy
Front view Front view
50 ADDRESS L
Assy
50 ADDRESS S
Assy
50 ADDRESS L
Assy
50 ADDRESS S
Assy

Pioneer PDP-507XD Specifications

General

Comb filter	3D
Aspect ratio	16:9
Product color	Black
Noise reduction	Yes
Display diagonal	50 \
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Viewable size diagonal	1270 mm
Contrast ratio (typical)	4000:1
