7. ADJUSTMENT
7.1 PARTS CHANGE OF NOTES
7.2 ADJUSTMENT REQUIRED WHEN THE SET IS REPAIRED OR REPLACED
1. At shipment, the unit is adjusted to its best conditions. Normally, it is not necessary to readjust even if an assembly is replaced. If the
adjustment is shifted or if it becomes necessary to readjust because of part replacement, etc., perform the adjustment as described below.
2. Any value changed in Service/Factory mode will be stored in memory as soon as it is changed. Before readjustment, take note of the
original values for reference in case you need to restore the original settings.
3. Use a stable AC power supply.
50Y MAIN DRIVE Assy No adjustment required
50Y SUB DRIVE Assy No adjustment required
TANSHI Assy No adjustment required
R07 DT Assy (PDP-507XD only) No adjustment required
POWER SUPPLY Unit
50 DIGITAL Assy
50X MAIN DRIVE Assy No adjustment required
Refer to "7.7 HOW TO CLEAR HISTORY DATA".
50X SUB DRIVE Assy No adjustment required
MAIN Assy Switching to SR+ from RS-232C
Service Panel Assy
Refer to "7.5
ADJUSTMENTS WHEN THE SERVICE
PANEL ASSY IS REPLACED" and "7.7 HOW TO
CLEAR HISTORY DATA".
Writing of backup data is required.
Refer to the "7.4 BACKUP WHEN THE PANEL UNIT
IS ADJUSTED. "
SENSOR Assy
Writing of backup data is required.
Refer to the "7.4 BACKUP WHEN THE PANEL UNIT
IS ADJUSTED. "
