11. SPECIFICATIONS
11.1 MAIN SPECIFICATIONS
*
1
Selectable from the menu
*
2
This conforms to HDMI1.1 and HDCP1.1.
HDMI (High Definition Multimedia Interface) is a digital interface that handles both video and audio using a single cable.
HDCP (High-bandwidth Digital Content Protection) is a technology used to protect copyrighted digital contents that use the
Digital Visual Interface (DVI).
Design and specifications are subject to change without notice.
Item 50" Plasma Television, Model: PDP-507XD
Number of Pixels 1365 x 768 pixels
Audio Amplifier 13 W + 13 W (1 kHz, 10 %, 8 )
Speakers
Surround System SRS/FOCUS/TruBass
Power Requirement 220 V to 240 V AC, 50 Hz/60 Hz, 348 W
(0.7 W Standby)
Dimensions 1224 mm (W) x 717 mm (H) x 115 mm (D)
Weight 34.7 kg (76.5 lbs.)
Colour System Analogue PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
Digital PAL/SECAM
TV Function
(Analogue)
Receiving System B/G, D/K, I, L/Lí
Tuner VHF/UHF E2–E69ch, F2–F10ch, I21–I69ch, IR A–IR Jch
CATV Hyper-band, S1ñS41ch
Auto Channel Preset 99 ch, Auto Preset, Auto Label, Auto Sort
STEREO NICAM/A2
TV Function
(Digital)
Receiving System DVB-T (2K/8K COFDM)
Tuner VHF/UHF VHF Band III (170 MHz to 230 MHz) and UHF Band IV, V (470 MHz to 862 MHz)
Auto Channel Preset 999 ch, Auto Preset, Auto Label, Auto Sort
STEREO MPEG layer I/II, Dolby Digital
Terminals Rear INPUT 1 SCART (AV in, RGB in, TV out)
INPUT 2
SCART (AV in/out, S-VIDEO in, AV link
*1) Component Video
INPUT 3
SCART (AV in/out, S-VIDEO in, RGB in, AV link
*1
), HDMI in
*2
INPUT 4
HDMI in
*2
CONTROL
OUT
1
SPEAKER 8 to 16
Antenna 75 Din Type for VHF/UHF in (Analogue)
75 Din Type for VHF/UHF in (Digital)
75 Din Type for VHF/UHF out (Digital)
PC Analogue RGB in PC INPUT (AUDIO)
Side INPUT 5 S-VIDEO, AV in
AUDIO OUTPUT Terminal (Rear) AUDIO out (Fixed)
SUB WOOFER OUTPUT Terminal (Rear) Variable
PHONES OUTPUT Terminal (Side) 16 to 32 recommended
DIGITAL OUT Terminal (Rear) Digital audio output (Optical)
COMMON INTERFACE (Rear) CA Module
1365 x 768 pixels
13 W + 13 W (1 kHz, 10 %, 8 )
SRS/FOCUS/TruBass
220 V to 240 V AC, 50 Hz/60 Hz, 341 W
(0.3 W Standby)
1224 mm (W) x 717 mm (H) x 115 mm (D)
34.1 kg (75.2 lbs.)
Model: PDP-507XA
(*)
(*)
(*)
(*)
(*)
(*) : PDP-507XD Only
