Pioneer PDP-507XD Service Manual

PDP-507XD
108
1234
1234
C
D
F
A
B
E
6.2 FLOWCHART OF THE MAIN PARTS AND PC BOARDS EXCHANGE
It is efficient to proceed with removal of the main parts and boards in the order shown in the chart below:
Note: Even if the unit shown in the photos and illustrations in this manual may differ from your product, the procedures
described here are common.
Chart of removal order for the main parts and boards
SIDE KEY
Function button
panel
1
Side input
cover
1
Rear case (507)
1
Terminal panel B
(50E)
3
Terminal panel A
2
Side input
panel (E)
SENSOR
TANSHI
SIDE
2
Side input
shield
Panel holder,
Front chassis VL
50 X MAIN
DRIVE
SP
TERMINAL
2
4
5
Function button
shield
Front case Assy
(507PE)
50 Y MAIN
DRIVE
2
MAIN
R07 DT
PDP-507XD
only
50 DIGITAL
50 Y SUB
DRIVE
AUDIO PC
50 X SUB
DRIVE
POWER
SUPPLY
50 SCAN A 50 SCAN B
50 LED LED IR

Pioneer PDP-507XD Specifications

General

Comb filter	3D
Aspect ratio	16:9
Product color	Black
Noise reduction	Yes
Display diagonal	50 \
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Viewable size diagonal	1270 mm
Contrast ratio (typical)	4000:1
