Pioneer PDP-507XD Service Manual

PDP-507XD
175
5678
56
7
8
C
D
F
A
B
E
9.3.13 OTHER COMMANDS
Command
Format
Operation
Remarks
Effective
Operation Modes
Control
[FAJ]
During FAY
To make the flag setting that
indicating that adjustment of the
panel unit has been completed
Writing 00 to the 4 k byte ROM and
copying to the 2 k byte ROM
This takes at least 350 ms.
[UAJ]
To make the flag setting that
indicating that adjustment of the
main unit has not been completed
Writing F0 to the 4 k byte ROM
[CBU]
To make the flag setting that
indicating that backup data
have not been copied
Writing F0 to the 2 k byte ROM The backup ROM is
initialized.
[BCP]
To copy Digital backup data
to EEPROM
Copying backup data
7 Backup function for adjustment values for the main unit • • • [FAJ/UAJ/CBU/BCP]
When the DIGITAL Assy is to be replaced, adjustment values can be copied from the backup EEPROM to the EEPROM
of the Assy for service.
7 Setting for Factory mode permission/prohibition • • • [FAY/FAN]
The commands FAY/FAN are for prohibiting/permitting panel-adjustment commands.
Command
Format
Operation
Remarks
Effective Operation
Modes
Control
[FAY]
Normal operation mode
while the power is on
Adjust command is valid.
Mask indications will be forcibly turned off.
[FAN]
During FAY Adjust command is invalid.

Pioneer PDP-507XD Specifications

General

Comb filter	3D
Aspect ratio	16:9
Product color	Black
Noise reduction	Yes
Display diagonal	50 \
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Viewable size diagonal	1270 mm
Contrast ratio (typical)	4000:1
