Pioneer PDP-507XD Service Manual

PDP-507XD
181
5678
56
7
8
C
D
F
A
B
E
10.4 LED INFORMATION
State
AC OFF or
Main power switch OFF
Standby power
management
Power ON
Power-down
Once OnceTwice n times500 msec 2.5 sec
Once OnceTwice n times500 msec
200 msec
200 msec
100 msec
100 msec
2.5 sec
Shutdown
No digital adjustment data
copied for backup
In the process of rewriting
the program of the
microcomputer
PDP- 507XD only
RS-232C <=> SR+ switch
During reservation
video recordings
(Unit: Standby)
During factory operation
During sleep timer operation (∗2)
During reservation video
recordings (Unit: ON) ∗1
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
LED Pattern
POWER ON STANDBY REC TIMER
∗1: PDP-507XD types
∗2: PDP-507XA types
LED Pattern

Pioneer PDP-507XD Specifications

General

Comb filter	3D
Aspect ratio	16:9
Product color	Black
Noise reduction	Yes
Display diagonal	50 \
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Viewable size diagonal	1270 mm
Contrast ratio (typical)	4000:1
