9.3.3 QIP
9.3.4 QAJ
Data Arrangement
Data
Length
Output Example
ECO 3 byte QIP
1 SERIAL 15 byte - - - - - - - - - - - - - - -
2 HOUR METER 8 byte 00000000
3 TOTAL HOUR METER 8 byte 00000000
4 PON COUNTER 8 byte 00000000
5 TEMP1 acquisition (Temperature value) 5 byte +23.5 (*1)
6 TEMP0 acquisition (Temperature value) 5 byte +28.7 (*1)
7 MAX-TEMP1 acquisition (Temperature value) 5 byte +78.3 (*1)
8 Reserved 4 byte ∗∗∗∗
CS 2 byte 94
Command
Format
Effective Operation
Modes
Function Remarks
[QIP] All operations
To acquire data on operations of the panel
Return data: 3 (ECO)+58(DATA)+2(CS)= 63 Byte
The command QIP is for acquiring data on operational information of the panel.
Note
(*1) : Centigrade scale
Data Arrangement
Data
Length
Output Example
ECO 3 byte QAJ
1 V-SUS adjustment value 3 byte 128
2 V-OFT adjustment value 3 byte 128
3 V-RST-P adjustment value 3 byte 128
4 Reserved 3 byte ∗∗∗
5 XSB adjustment value 3 byte 128
6 YSB adjustment value 3 byte 128
7 YTG adjustment value 3 byte 128
11 RYW adjustment value 3 byte 128
12 R-REVICE setting value 1 byte 0
13 G-REVICE setting value 1 byte 0
8 YTW adjustment value 3 byte 128
9 RSW adjustment value 3 byte 128
10 YTB adjustment value 3 byte 128
14 B-REVICE setting value 1 byte 0
CS 2 byte B7
• For each REVISE setting value, the level set for RRL, RGL, or RBL is transmitted as one character.
Command
Format
Effective Operation
Modes
Function Remarks
[QAJ] All operations
To acquire data on operations of the panel
Return data: 3 (ECO)+41(DATA)+2(CS)= 46 Byte
The command QAJ is for acquiring the panel's factory-preset data.
