9.3.8 QSD
Data Arrangement
Data
Length
Output Example
ECO 3 byte QSD
1 Latest SD data 1 byte 1
2 Latest SD subcategory data 1 byte 0
3 Data from the hour meter for the latest SD 8 byte 00752013
4 Second latest SD data 1 byte 5
5 Second latest SD subcategory data 1 byte 0
6 Data from the hour meter for the second latest SD 8 byte 00495204
7 Third latest SD data 1 byte 2
8 Third latest SD subcategory data 1 byte 3
9 Data from the hour meter for the third latest SD 8 byte 00100355
10 Fourth latest SD data 1 byte 2
11 Fourth latest SD subcategory data 1 byte 5
12 Data from the hour meter for the fourth latest SD 8 byte 00075620
13 Fifth latest SD data 1 byte 1
14 Fifth latest SD subcategory data 1 byte 0
15 Data from the hour meter for the fifth latest SD 8 byte 00000852
16 Sixth latest SD data 1 byte 2
17 Sixth latest SD subcategory data 1 byte 5
18 Data from the hour meter for the sixth latest SD 8 byte 000000451
19 Seventh latest SD data 1 byte 0
20 Seventh latest SD subcategory data 1 byte 0
21 Data from the hour meter for the seventh latest SD 8 byte 00000000
22 Eighth latest SD data 1 byte 0
23 Eighth latest SD subcategory data 1 byte 0
24 Data from the hour meter for the eighth latest SD 8 byte 00000000
CS 2 Byte 7D
Command
Format
Effective Operation
Modes
Function Remarks
[QSD] All operations To acquire data on the shutdown logs Return data: 3 (ECO)+80(DATA)+2(CS)= 85 Byte
The command QSD is for acquiring the data from the 8 latest shutdown (SD) logs.
¶ SD data
0 No SD
1 SQ-IC
2 MDU-IIC
3 RST2
4 TEMP
¶ SD subcategory (SQ-IC)
0 No SD-Sub data
1 Communication error
2 Drive stop
6 Version mismatching
3 BUSY
¶ SD subcategory (MDU-IIC)
0 No SD-Sub data
1 EEPROM
2 BACKUP
3 DAC
¶ SD subcategory (TEMP)
0 No SD-Sub data
1 TEMP1
2 Reserved
